Oblique of pictorial drawing

• What does the term "cavalier" refer to in oblique pictorial drawing?

  Cavalier refers to measurements of width, height, and depth/length in full size.
• What does "full size" mean in the context of oblique pictorial drawing?

  Full size means that the measurements of width and height are in full size while the depth or length is two-thirds.
• How is the depth or length represented in a full-size drawing?

  The depth or length is represented as two-thirds of the actual size.
• What does "cabinet" refer to in oblique pictorial drawing?

  Cabinet refers to measurements of width and height in full size while its depth or length is one-half.
• How is the depth or length represented in a cabinet drawing?

  The depth or length is represented as one-half of the actual size.
• What are the key differences between cavalier and cabinet oblique pictorial drawings?

  • Cavalier:
  • Width and height in full size
  • Depth or length is full size
  • Cabinet:
  • Width and height in full size
  • Depth or length is one-half of the actual size
